LIFUD 75W AUP IP67 24vDC 3.125A Adjustable LED DRIVER

Constant-voltage LED driver designed to provide stable 24V DC power for LED strip lighting, signage and other low-voltage lighting systems. Its IP67-rated metal enclosure provides excellent protection against dust and water, making it suitable for both indoor and outdoor installations.

Key Features

• 75W output power
• 24V DC constant-voltage output
• 3.125A output current
• Adjustable 22–26V DC output
• IP67 protection
• Flicker-free operation
• High efficiency
• Wide 100–277V AC input range
• Enclosed metal housing
• Fanless design
• Built-in electrical protection
• 5-year warranty

Ideal Applications

• 24V LED strip lighting
• LED signage and displays
• Architectural lighting
• Outdoor lighting
• Commercial lighting
• Residential lighting
• Other 24V constant-voltage LED systems

Technical Summary

• Brand: Lifud
• Model: LF-GOE075YV024A
• Output Type: Constant Voltage
• Output Voltage: 24V DC
• Output Current: 3.125A
• Output Power: 75W
• Input Voltage: 100–277V AC (max. 305V AC)
• Input Current: 0.85A max.
• Output Voltage Adjustment: 22–26V DC (92–108%)
• Efficiency: ≥87.5% at 230V AC full load
• Power Factor: ≥0.95
• Flicker: ≤0.5%
• IP Rating: IP67
• Dimmable: No
• Cooling: Fanless
• Operating Temperature: -40°C to +60°C
• Dimensions: 169.4 × 61 × 34mm
• Housing: Metal enclosed
• Input Connection: Mains plug & flex
• Output Connection: 250mm sheathed cable
• Protection: Over-voltage, over-current, short circuit and surge protection
• Surge Protection: 6kV L-N / 8kV L/N-GND
• Warranty: 5 years
